Drilling Machine

Industrial brand ORION drill, drilling and milling machines, tapping machines, multipurpose attack machines, vertical drilling machines, radial drilling machines | with a production capacity of 50,000 units per year, with 8 series and more than 70 types. advanced technology, complete production and testing equipment, stable and reliable product quality, strong after-sales service, products and services supported by users. The spirit of corporate culture to keep pace with time, year after year is approved to maintain and win awards, "user trust", "sophisticated civilization", AAA is the value of the company which increases the level of products in accordance with national standards and production standards and inspection companies , the company has passed ISO9001: 2008 international system certification system.




click image to enlarge
Client : PT.  Metso Mineral Indonesia
Location : Sidoarja - Jawa Timur
Model : Z3040X13
Country Of Origin : Taiwan
Spindle Travel : 275 mm
Distance Spindle Axis To Column Surface : 200-1300 mm
Distance Spindle Nose To Base Table : 300-1250 mm
Motor Power : 3000W
Power Supply : 3 Phase, 380(V)/50(Hz)
Motor Of Arm Elevation : 750W
Net/Gross Weight : 2000/2100Kg
Max Drilling Capacity (Cast Iron/Steel) : 40 mm
Spindle Taper :  MT4
The Rotation Of Arm In Horizontal Plane : 360°
Horizontal Travel Of Head Stock : 1100 mm
Vertical Travel Of Radial Arm : 675 mm
Spindle Speeds Range : 54-1360r/min
utline Dimension (L*W*H) : 2030 x 840 x 2540  mm
Warranty : 3 Years (Mechanical) 1 Year (Electrical)
