Orion Drilling & Milling Machine ZX-40PC ZX

Product Specification

Best Price : Rp 46,130,432 / Unit
Promo Price : Rp 33,213,911 / Unit

* Price exclude PPN, Ex-Works Cikupa
* Price & Spec can be changed without prior notification

SKU - DCE-13157
ORION Drilling & Milling Machine
• Model : ZX-40PC
• Max drilling capacity Cast Iron/Steel (mm) : 40/32
• Width of face milling (mm) : 80
• Diameter of vertical milling (mm) : 22
• Diameter of column (mm) : 115
• Spindle travel (mm) : 120
• Max distance spindle nose to table (mm) : 745
• Max distance spindle nose to base (mm) : 1245
• Spindle taper : MT4
• Spindle speeds range (r/min), series : 95~1600, 6
• Dimension of worktable surface (mm) : 585x190
• Table travel (mm) : 370x140x515
• Dimension of base (mm) : 690x520
• Overall height (mm) : 1810
• Main motor : 750W, 1Phase 220V
• Coolant motor : 40W
• Net weight (KG) : 335
• Packing dimension (cm) : 72x74x198
• Warranty : Mechanical 36 Months , Electrical 12 Months
Featuress :
+ Heavy duty Polyurethane coating by Jotun, Norway
+ Column precise material by Hitachi Alloy, Japan
+ Precision Gear by Neugart Gmbh., Germany
+ Gearbox Parts by Hitachi Alloy, Japan
+ Be equipped with coolant system
+ Safe design with international quality
+ Easy maintenance and low noise
+ Simple structure and less failure
+ High accuracy & precision

REQUEST QUOTE
Get your quotation less than 1 minute now!!

GEAR HEAD DRILLING & MILLING MACHINE SPECIAL FEATURES :

Drilling & milling machine dilengkapi dengan roda Gigi yang dikeraskan, torsi besar yang digerakkan tipe B1 opsional 2x kecepatan motor,
Dilengkapi dengan mesin yang telah teruji, kuat, mudah dioperasikan lebih sederhana, perawatan mudah, dan rendah kebisingan.
Dalam produksi jumlah besar, sistem kelistrikan mesin dapat mencapai sirkulasi otomatis pengumpanan spindel dan memulai sirkulasi tunggal.
Dilengkapi dengan akurasi pemosisian tinggi dan kecepatan gerak, yang dapat diterapkan dalam pemrosesan komponen dengan multi threads.

Memiliki desain integrasi elektromekanis untuk memastikan struktur yang kompak dan penggerak motor yang mudah dioperasikan.
Dengan standar kualitas internasional membuktikan sebagai mesin bor terbaik sepanjang masa. Orion adalah pilihan terbaik.
Sangat mudah diinstalasi dan mudah saat dioperasikan, sehingga pekerjaan lebih ringan hemat waktu, hemat biaya dan hemat energi.
Bagian poros dibuat oleh material permukaan baja berkualitas tinggi khusus dibuat oleh peralatan kelas satu, kekuatan tinggi dan daya tahan lebih lama.

Digunakan dalam industri konversi, yaitu konversi mesin bubut dalam jumlah besar mampu diberbagai layanan bengkel, pabrik, dll.
Drilling & milling machine Tidak menggunakan terlalu banyak daya listrik, yang tentunya akan menghemat biaya pengeluaran anda.
Drilling & milling machine sangat mudah diaplikasikan sehingga sangat cocok untuk keperluan bisnis anda.
Drilling & milling machine system memberikan garansi selama satu tahun

With wide range of speed, with manual, power feeds. The feed of machines are very easily engaged and disengaged at anytime.
