Tomori Industrial Direct System Block Ice Machine


Tomori Industrial Direct System Block Ice Machine - Direct system refrigeration block ice machine is adopted by modular design. The large capacity direct refrigeration block ice machine is divided into machine unit modular, evaporator modular and cooling tower modular, the evaporator modular is divided into many sets according to size of ice machine

Tomori Industrial Ice Block Machine 20 Ton - Direct System TMB-200D FC

Product Specification

Best Price : Rp 3,146,836,414 / Unit
Promo Price : Rp 2,265,722,218 / Unit

* Price exclude PPN, Ex-Works Cikupa
* Price & Spec can be changed without prior notification

SKU - DIR-17
Tomori Industrial Ice Block Machine - Direct System
Model : TMB-200D
Capacity in 24 hours : 20 Tons
Voltage : 380V/3 Phase/50Hz
Power : 145 KW
Required Netto Power by PLN : 290 KW
Dim. Unit (LxWxH) : 12.200x2260x2250 MM
Refrigerant : R404A, Ice Type : Block
Weight of Unit and Evaporator: 20.800 Kgs
Weight of Cooling Tower : 1300 Kgs, Compressor : Bitzer 110 HP (90 kW)
Advanced Japan Technology
Warranty : 1 Years Electrical & Mechanical
Features;
- Ultra Duty Compressor By Bitzer Sindelfingen, Germany
- Evaporator material special alumunium by Hitachi Alloy, Japan
- PLC control and support WIFI System by Flexem, Germany
- Valves by Danfoss Genuine Parts, Denmark
- Heavy Duty Polyurethane Protective Coating By Jotun, Norway
- Electrical System by Siemens Genuine Part, Germany
- Switches by Schneider Genuine Parts, France
- Machine Oil By Suniso Oil, Japan
- Refrigerant R404A by Chemours, USA
- Ice Block 50 Kgs for 10 tons below and 25 kgs for 15 tons to 30 tons
- Right Side, Outward or Stoping Down System for Ice Harvest
- Free other parts for first Instalation
- Full Capacity design guarantee
- Durable and food grade ice can
- Full Automatic thawing for ice doffing
- Less Human Resources to make high efficiency in productivity
- Strong and special material construction

REQUEST QUOTE
Get your quotation less than 1 minute now!!

TOMORI INDUSTRIAL BLOCK ICE MACHINE :
ICE BLOCK MACHINE WITH GERMAN TECHNOLOGY, THIS LATEST TECHNOLOGY ENSURES
THAT THE COOLING EVAPORATOR WORKS MUCH FASTER WITH MAXIMUM COOLING PERFORMANCE.

DIRECT REFRIGERATION BLOCK ICE MACHINE TECHNICAL PARAMETER

Model		TMB-200D
Daily Capacity		20T
Refrigerant		R22/R404A
Electricity Consumption		85.55 Kw
Install Power		105 Kw
Operating Weight		2896 Kg
Size (LWH)		240016001800 mm
Standard condition: Dry bulb temperature is 33°C and water inlet temperature is 20°C.

DIRECT SYSTEM BLOCK ICE MAKING PROCESS

Water will be added automatically to ice cans and directly exchange heat the refrigerant. When ice making is finished, the refrigeration system will change into ice doffing mode automatically in which HPHT refrigerant air will release heat to melt the surface of block ice. All the ice blocks will fall down in 25 minutes.

FEATURES

The evaporator adopts special alumunium alloy plate which is more durable and meets food hygiene requirements.
Ice thawing and ice doffing are fully-automatic.
The ice is doffed by batch and the whole ice-doffing process only takes 25 minutes.
The whole batch of ice blocks can be moved by forklift, quick and convenient.

DIRECT REFRIGERATION BLOCK ICE MACHINE TECHNICAL PARAMETER

Model Weight (Kg/Block)	Dimension (mm)	Ice Making time (Hour)	Batch (Times)
5	125100600	5.5	4
10	155100750	5.5	4
15	185125750	7.5	3
20	245125750	7.5	3
25	315125750	7.5	3
50	480160750	11.5	2
The maximum length of block ice from alumunium system is 750mm and the size can be customerized.

download catalog Waxler Packaging Equipments

TOMORI DIRECT SYSTEM BLOCK ICE MACHINE TMB-100D TOMORI DIRECT SYSTEM BLOCK ICE MACHINE TMB-300D
