Counterbalanced Electric Reach Stacker

Jual Counterbalanced Electric Reach Stacker, Counterbalanced Electric Reach Stacker, dengan Harga Murah

Jual Counterbalanced Electric Reach Stacker - Shigemitsu is one of best company in material handling equipment especially hand pallet truck & manual stacker.

Since decades it's develop special technology on heavy duty product to fulfill customer's need on durable products. Shigemitsu is the name of premium line of Heavy Duty Hand Pallet & Manual Stacker with 3 Years Warranty & 60.000 cycles. Shigemitsu Special hydraulic pump will allow you to enjoy real "strong" performance.

KQD15R
Counterbalanced Electric Reach Stacker KQD15R
MODEL KQD15R
Load Capacity : 1500 Kg
Load Centre : 500 mm
Load Distance : 520 mm
Tyre size, front : Φ 250 x 70 mm
Tyre size, rear : Φ 210 x 85 mm
Balance wheel size : Φ 150 x 60 mm
Wheels, number front rear (x=driven wheels) : 1x+2/2
Forks, tilt forward/ back : 3/6
Height, mast lowered : 1820/2118/2400/1953/2128/2298/2495 mm
Free lift (option) : 0/ 0 / 0/1280/1480/1600/1870 mm
Max. lift height : 2500/3000/3500/4000/4500/5000/5600 mm
Height, mast extended : 3500/4000/4500/5000/5500/6000/6600 mm
Height of tiller in drive position min./ max : 1160/1460 mm
Overall length : 2250 mm
Length to face of fork : 1200 mm
Overall width : 990 mm
Fork dimension : 35/100/950 (1070/1150) mm
Fork carriage width : 220-680 mm
Reach distance : 650  mm
Aisle width for pallets 800x1200 lengthways : 2750 mm
Turning radius : 1750 mm
Travel speed, laden/ unladen : 6.8/7 mm
Lifting speed, laden/ unladen : 0--0.13/0--0.2 m/s
Lowering speed, laden/ unladen : 0--0.42/0--0.41 (adjustable) m/s
Battery voltage, nominal capacity K5 : 24/270 V/Ah
Battery weight : 260-320 Kg
Battery dimensions (I/W/H) : 825x213x590 mm
Service weight (with battery) : 2140 Kg
  • AC power to platform
  • Pothole Guards
  • Overload sensor with alarm
Price list
KQD15R  Standing Type - 1.5T, 3.0M Rp. 197.641.000-,
KQD15R  Standing Type - 1.5T, 3.5M Rp. 199.889.000-,
KQD15R  Standing Type - 1.5T, 4.0M Rp. 213.309.000-,
KQD15R  Standing Type - 1.5T, 4.5M Rp. 216.511.000-,
KQD15R  Standing Type - 1.5T, 5.0M Rp. 219.713.000-,
KQD15R  Standing Type - 1.5T, 5.6M Rp. 232.179.000-,
 * Harga diatas sudah termasuk PPn
* Gratis ongkir untuk Jabodetabek, Surabaya, Medan & Bandung

Dimension KQD15R

Counterbalanced electric reach stacker Specs


COUNTERBALANCED ELECTRIC REACH STACKER FEATURES :

  • jual hand pallet

    Roda kemudi vertikal, yang lebih efisien dalam mengemudi,serta pemasangan & perawatan mudah.

  • jual hand pallet

    Memiliki sakelar berhenti darurat dan tombol kunci listrik, dan tuas pengontrol multi-katup,

  • jual hand pallet

    Meter dengan BDI, memperpanjang waktu penggunaan baterai.

  • jual hand pallet

    Memiliki Dua silinder pengangkat yang ditempatkan di sisi luar tiang.

  • jual hand pallet

    Memiliki Sistem Pengendalian AC, kebisingan rendah,serta perawatan yang mudah.

  • jual hand pallet

    Baterai penyimpanan tinggi memastikan daya yang kuat dan tahan lama.

  • jual hand pallet

    Dilengkapi Katup regulator yang dapat disetel, dapat menyesuaikan kecepatan rendah tiang.

  • jual hand pallet

    Memiliki Garpu sistem titiling yang mudah untuk memuat dan menumpuk barang.
