Narrow Aisle Forklift Truck

Jual Narrow Aisle Forklift Truck ND10B - Shigemitsu


Narrow Aisle Forklift Truck ND10B
Narrow Aisle Forklift Truck Specs

Price list
 ND10B  1.0T, 5.0M
   Rp. 358.166.000-,
 ND10BC  Side Shifter - 1.0T, 5.0M
   Rp. 374.602.000-,
 ND10BZ  Free Lift - 1.0T, 5.0M
   Rp. 372.130.000-,
 * Harga diatas sudah termasuk PPn
* Gratis ongkir untuk Jabodetabek, Surabaya, Medan & Bandung


Model : ND10B
  Power    Battery
  Capacity/ rated load Q (Kg) 1000
  Load centre distance c (mm) 500
  Max. lift height h3 (mm) 5000
  Load distance, centre of drive axle to fork x (mm)
180
  Tyre size, front (mm)
Φ 250x80
  Tyre size, rear (mm)
Φ 280x100
  Variation of side shifter, left/ right mm 0
  Height, mast lowered h1 (mm) 2255
  Free lift H2(mm)   ~
  Height, mast extended H4 (mm) ~
  Height of overhead guard (cabin) H6 (mm) 2090
  Height of tiller in drive position min./ max. H14 (mm) 1000
  Overall length I1 (mm) 2250
  Overall width b1 (mm) 850
  Fork dimension s/e/I (mm)
35/100/950
  Fork carriage DIN 15173, class/ type A, B
II/A
  Fork carriage width b3 (mm)
560
  Ground clearance, centre of wheelbase m2 (mm) 50
  Aisle width for pallets 1000x1200 Crossways Ast (mm) 2750
  Aisle width for pallets 800x1200 Lengthways Ast (mm) 2860
  Turning radius Wa (mm) 1250
  Travel speed, laden/ unladen (Km/h) 5.8/6.0
  Lifting speed, laden/ unladen (m/s) 0.15/0.25
  Lowering speed, laden/ unladen (m/s) 0.08/0.10
  Battery voltage, nominal capacity K5 V/Ah 24/360
  Battery weight (Kg) 355
  Battery dimension I/w/h (mm)
610x278x690
  Service weight (with battery) (kg) 2230


Advantage
Advance AC control system with MOSFET delivers smooth driving speed control for precise.
Small turning radius, easy and smart to operate.
Lean-on compartment reducing operator's fatigue.
With regenerative braking system for driving and electronic braking system for parking.
Low Battery protection setting prolongs service life.
Wih deadman switch on floor to cut off the power when operator leave the foot from cab.
Lifting cylinders on the both of mast provides best visibility.
The optional of Full Hydraulic Steering System
Steering wheel automatic reset.
Traveling speed automatically slow down when steering.
Show the turning angles on the display.
