Masterpac Compaction Equipment

Jual Forward Plate Compactor 80-130Kgs - Masterpac

  • Solid, high strength steel base plate with curved edges provides top performance.
  • Cast Iron wear resistant lubricated vibrator assembly.
  • Robust design sealed belt cover for Clutch and Belt protection.
  • Self cleaning open base plate minimizes dirt and rock build up.
  • Anti vibration removable flip over handle for easy transportation.
  • Solid engine frame with lifting eye protect engine against dirt and damaging and for easy transportation.
  • Built-in transport wheel for easy transportation around sites.
  • Optional water tank for asphalt use.
  • Optional polyerthene pad for paving applications also available.
  • Sturdy protected throttle lever.
  • Powered by gasoline as HONDA, ROBIN, and diesel as LOMBARDINI, HATZ.

Product Detail

Working Size (mm)

Model A B C D
PC4012 Series
PCV4012 Series
1030/40 970/38 565/22 400/16
PC4515 Series
PCV4515 Series
1070/42 940/37 565/22 45018
PC5018 Series
PCV5018 Series
1045/41 945/37 565/22 500/20
PC5021 Series
PCV5021 Series
1065/41.9 950/37 565/22 500/20


Technical Specification

Model PC4012H
PCV4012H
PC4012R
PCV4012R
PC4012L
PCV4012L
PC4012A
PCV4012A
Engine Type Honda GX160 Robin EX17 Lombardini LD225 Hatz1B20
Power kw(hp) 4.0(5.5) 4.2(5.7) 3.5(4.8) 3.5(4.8)
Weight kg(lb) 85(187) 85(187) 98(216) 98(216)
Plate Size L×W cm(in) 57×40(22×16)
Centrifugal Force kN 12
Vibration Frequency vpm(Hz) 5400(90)
Travel Speed m/min(ft/min) 22(72)

Model PC4515H
PCV4515H
PC4515R
PCV4515R
PC4515L
PCV4515L
PC4515A
PCV4515A
Engine Type Honda GX160 Robin EX17 Lombardini LD225 Hatz1B20
Power kw(hp) 4.0(5.5) 4.2(5.7) 3.5(4.8) 3.5(4.8)
Weight kg(lb) 90(198) 90(198) 103(227) 103(227)
Plate Size L×W cm(in) 57×45(22×20)
Centrifugal Force kN  15
Vibration Frequency vpm(Hz)  5400(90)
Travel Speed m/min(ft/min)  24(78)

Model PC5018H
PCV5018H
PC5018R
PCV5018R
PC5018L
PCV5018L
PC5018A
PCV5018A
Engine Type Honda GX160 Robin EX17 Lombardini LD225 Hatz1B20
Power kw(hp) 4.0(5.5) 4.2(5.7) 3.5(4.8) 3.5(4.8)
Weight kg(lb) 90(198) 90(198) 126(278) 126(278)
Plate Size L×W cm(in) 57×50(22×20)
Centrifugal Force kN 18
Vibration Frequency vpm(Hz) 5400(90)
Travel Speed m/min(ft/min) 20(66)

Model PC5021H
PCV5021H
PC5021R
PCV5021R
PC5021L
PCV5021L
PC5021A
PCV5021A
Engine Type Honda GX160 Robin EX17 Lombardini LD225 Hatz1B20
Power kw(hp) 4.0(5.5) 4.2(5.7) 3.5(4.8) 3.5(4.8)
Weight kg(lb) 115(254) 115(254) 128(282) 128(282)
Plate Size L×W cm(in) 57×50(22×20)
Centrifugal Force kN 21
Vibration Frequency vpm(Hz) 5400(90)
Travel Speed m/min(ft/min) 22(72)

Note : Honda & Robin is Gasoline type engine; Lombardini & Hatz is Diesel type engine
