Heavy Duty BOMAC Forklift Electric - Bomac Forklifts Electric with strong & reliable performance, using the best engine in its class and specially designed with adjusted weight, so that it is stable and safe when used.

BOMAC is now vigorously improving its services and products with high quality, enabling dealers to meet all customer needs. Based on experience, stability and responsibility, BOMAC Forklifts is more than 30 years old with deep connotation, rich experience and many achievements.
Bomac Forklift Electric 2.5T RE25-A2 AN Standart Lift 3M - Zapi Controller
Product Specification
Best Price : Rp 399,843,247 / Unit
Promo Price : Rp 287,887,138 / Unit

* Price exclude PPN, Ex-Works Cikupa
* Price & Spec can be changed without prior notification

SKU - DHE-15305
BOMAC Heavy Duty Electric Forklift, with ZAPI Controller, made in ITALY
• Model : RE25-A2
• Power Type : Electric
• Capacity : 2500kg
• Lifting Height : 3 meter
• Mast Height : 2000mm
• Load Center : 500mm
• Free Lift Height : 170mm
• Fork Size : 40x122x1070mm
• Turning Radius : 2065 mm
• Controller : ZAPI - Made in ITALY
• Drive Motor-60 Min, Rating : 11.1(AC)
• Pump Motor-15 Min. Rating : 10.5(DC)
• Drive/Pump Motor Control : Mosfet AC/Mosfet DC
• Battery Voltage/Capacity : 48V/600Ah
• Warranty : Mechanical 36 Months , Electrical 12 Months
Features
+ Rust free hydraulic piston rod by HITACHI ALLOY, Japan
+ Heavy duty polyurethane coating with JOTUN, Norway
+ Heavy duty wear resistant fork by HARDOX, Sweden
+ Mast by Winkel GmbH, Germany
+ Electrical by EATON, England
+ Controller by ZAPI, Italy
+ Seal by NOK, JAPAN
+ BOMAC Advance Safety (BAS) Package
+ Maintenance free and long service life
+ High efficiency and energy saving
+ Super low torque steering unit makes steering light and easy
+ LED lights are more energy saving
+ Automatic deceleration when steering improves working safety
REQUEST QUOTE
Get your quotation less than 1 minute now!!
Bomac R Series Characteristic Jual Forklift Elektrik 1 Ton Bomac - Specs

Manufacturer's Data and Design Characteristics
Manufacturer Bomac
Model RE25
Configuration Number A1/A2
Rated Capacity Q kg 2500
Load Center Distance c mm 500
Power Mode Battery
Driving Mode Seated
Wheel Base L1 mm 1535
NOTE:*For detailed information, please contact our salesmen or engineer.


WIDE VIEW MAST
Mast Model Max.Lifting height (mm) Load Capacity
(Load Center 500mm) (kg)
Mast Overall Height
(Fork to the ground) (mm)
Service Weight (kg) Mast tilt angle (°)α/β
M200 2000 1000 1495 2615 6/12
M250 2500 1000 1745 2645 6/12
M300 3000 1000 1995 2680 6/12
M330 3300 1000 2145 2700 6/12
M350 3500 1000 2245 2710 6/12
M370 3700 1000 2345 2725 6/6
M400 4000 1000 2545 2775 6/6
M425 4250 1000 2670 2790 6/6 | *6/12
M450 4500 950 2795 2805 6/6 | *6/12
M500 5000 930 3045 2840 6/6 | *6/6
M550 5500 900 3345 2900 *3/6
M600 6000 600 | *850 3595 2930 *3/6
NOTE: (1) *refers to rated capacity with double tires

Jual Forklift Elektrik 1 Ton Bomac - Specs

WIDE VIEW FULL FREE 2-STAGE MAST
Mast Model Max.Lifting height (mm) Load Capacity
(Load Center 500mm) (kg)
Mast Overall Height (mm) Free Lifting Height (with backrest)(mm) Service Weight (kg) Mast tilt angle (°)α/β
ZM200 2000 1000 1495 485 3660 6/12
ZM250 2500 1000 1745 735 2690 6/12
ZM300 3000 1000 1995 985 2725 6/12
ZM330 3300 1000 2145 1135 2750 /6126
ZM350 3500 1000 2245 1235 2760 6/12
ZM370 4000 1000 2345 1335 2775 6/6
ZM400 4000 1000 2545 1535 2825 6/6
ZM425 4250 1000 2670 1660 2840 6/6 | *6/12
ZM450 4500 950 2795 1785 2860 6/6 | *6/12
ZM500 5000 930 3045 2035 2895 6/6 | *6/6
ZM550 5500 900 3345 2335 2955 *3/6
ZM600 6000 600 | *850 3595 2585 2990 *3/6
NOTE:
(1) *refers to rated capacity with double tires
(2) 1-1.8T: free lifted height 365mm increased without backrest
(3) 2-2.5T: free lifted height 290mm increased without backrest


WIDE VIEW FULL FREE 3-STAGE MAST
Mast Model Max.Lifting height (mm) Load Capacity
(Load Center 500mm) (kg)
Mast Overall Height (mm) Free Lifting Height (with backrest)(mm) Service Weight (kg) Mast tilt angle (°)α/β
ZSM360 3600 1000 1790 695 2775 6/6
ZSM400 4000 1000 1925 910 2800 6/6
ZSM435 4350 950 2040 1025 2820 6/6
ZSM450 4500 950 2090 1075 2830 6/6
ZSM470 4700 930 2160 1075 2850 6/6
ZSM480 4800 920 2190 1145 2860 6/6
ZSM500 5000 900 2290 1275 2880 6/6
ZSM540 5400 750 | *900 2415 1400 2900 3/6
ZSM600 6000 550 | *1050 2640 1625 2975 3/6
ZSM650 6500 *1000 2640 1815 3010 3/3
ZSM700 7000 *750 3052 2010 3050 3/3
NOTE:
(1) *refers to rated capacity with double tires
(2) 1-1.8T: free lifted height 480mm increased without backrest
(3) 1-1.8T: free lifted height 440mm increased without backrest when assembled with pulley block
(4) 2-2.5T: free lifted height 320mm increased without backrest
(5) 2-2.5T: free lifted height 90mm increased without backrest when assembled with pulley block

Jual Forklift Elektrik 1 Ton Bomac - Specs


Wide view basic mast
Standard fork
II (III) stage fork arm carrier
Backrest
Control valve
Battery
Standard seat
Overhead guard
Overhead guard rain cover
Liquid crystal combined instrument
Pneumatic tyre
Traction pin
Driver's tool
LED Lamp
Horn alert function on rear handle

String rod
Driver's cab
lifting hock
Cargo boom
Tip-over fork
back view mirror
Side shifting
Paper roll clamp
Warning light (Flashing, totating, buzzing)
Solid type
Rear working light
Steel protection net
Multipurpose drum clamp
Load stabilizer
Widen fork arm carrier
Lengthening fork
Load pusher
Lengthening fork extension
Rotating flat clamp
Widen tyre protection device
Auxiliary hydraulic valve component
Tilting/steering cylinder jacket
Coloring tyre
Wide view two/three stage full free mast
Costumer made color
Turn automatic deceleration function
Battery lifting sling
